SOLAR POWERED SOLUTIONS

Gross volume (l): 250
Vaccine storage capacity (l) : 220
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): 111
Vaccine storage capacity (l) : 89
Ice-pack storage capacity (at 0.6 L): -
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): 187
Vaccine storage capacity (l) : 156
Ice-pack storage capacity (at 0.6 L): -
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): R = 79 / F = 42
Vaccine storage capacity (l) : 70
Ice-pack storage capacity (at 0.6 L): 17
Energy source: 8 solar panels (100 W / 12 V)

Gross volume (l): R = 118 / F = 42
Vaccine storage capacity (l) : 99
Ice-pack storage capacity (at 0.6 L): 24
Energy source: 8 solar panels (100 W / 12 V)

Gross volume (l): 64
Ice-pack storage capacity (at 0.6 L): 60 + 8
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): 46.6
Vaccine storage capacity (l) : 36
Ice-pack storage capacity (at 0.6 L): -
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): R = 46,6 / F = 4,8
Vaccine storage capacity (l) : 36
Ice-pack storage capacity (at 0.6 L): 8
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): R = 26,5 / F = 2,4
Vaccine storage capacity (l) : 16
Ice-pack storage capacity (at 0.6 L): 4
Energy source: 4 solar panels (100 W / 12 V)

Gross volume (l): 24.5
Vaccine storage capacity (l) : 16
Ice-pack storage capacity (at 0.6 L): -
Energy source: 4 solar panels (100 W / 12 V)

Combined Solar Direct Driven vaccine refrigerator and icepack freezer. Solar panels are connected plug & play directly to the appliances.
W.H.O. Approved PQS Code E003/092

Combined Solar Direct Driven vaccine refrigerator and icepack freezer. Solar panels are connected plug & play directly to the appliances.
W.H.O. Approved PQS Code E003/091

New integrated ice bank technology with increased storage capacity provides selfcontrolling and reliable temperatures in the area of +2°C to +8°C within a large ambient temperature area of +5°C to +43°C.
W.H.O. Approved PQS Code E003/054

New integrated ice bank technology with increased storage capacity provides selfcontrolling and reliable temperatures in the area of +2°C to +8°C within a large ambient temperature area of +5°C to +43°C.
W.H.O. Approved PQS Code E003/053

New integrated ice bank technology with increased storage capacity provides selfcontrolling and reliable temperatures in the area of +2°C to +8°C within a large ambient temperature area of +5°C to +43°C.
W.H.O. Approved PQS Code E003/041

New integrated ice bank technology with increased storage capacity provides selfcontrolling and reliable temperatures in the area of +2°C to +8°C within a large ambient temperature area of +5°C to +43°C.
W.H.O. Approved PQS Code E003/069

Unique freezing system and solar technology provide efficient ice pack freezing and storage capacity. Place 3 ice packs in the freezing compartment and 24 hrs later the ice packs are frozen and ready for use.
